Product Details:
Payment & Shipping Terms:
|
| Type: | Battery Charger | Warranty: | 1 Year |
|---|---|---|---|
| Use: | Lead Acid Lithium Battery , Lifepo4 Battery Pack | Material: | Aluminium Alloy |
| Application: | Electric Vehicle | Lifetime: | 30000 Hours |
lithium ion battery charger 67.2v Specifications:
| Input Voltage Range | AC 100~240V 50/60HZ |
| Output Voltage | 67.2V |
| Output Current | 5A |
Features:
1. Charging mode:CC—CV(Constant Current—Constant Voltage)
2. High efficiency and low power consumption
3. Stabilized output and low noice
4. Efficiency(at 100% load): >=80%
5. Operating temperature:0C ~ 45C
6. Storage temperature:-20C ~ 70C
7. Operating humidity:5%~90%RH
8. Rechangeable input plug(Customized)
9. Output Connector: DC, JST, XRL, Alligator Clip,Air plug and so on.
| No. | Output | Constant Voltage (CV) | Constant Current (CC) | Transition / Cut-off Current | Hot Sales | ||||
| Lead Acid | Li-MnO2 | LiFePO4 | Lead Acid (A) | Li(A) | |||||
| 1 | 12V | 14.7V | 16.8V | 14.6V | 20A | 4 | 1 | 48V@5A Lead acid battery charger for golf cart For Ez Go Club Car DS EZGO TXT with RXV Plug | 48v@6A Golf Cart Battery Charger 6 Amp YAMAHA* CLUB CAR, Yamaha G19-G22, 2 Pin Plug |
| 2 | 24V | 29.4V | 29.4V | 29.2V | 12A | 2.4 | 0.6 | ||
| 3 | 36V | 44.1V | 42.0V | 43.8V | 8A | 1.6 | 0.4 | ||
| 4 | 48V | 58.8V | 54.6V | 58.4V | 6A | 1.2 | 0.3 | ||
| 5 | 60V | 73.5V | 75.6V | 73.0V | 5A | 1 | 0.25 | ||
| 6 | 72V | 88.2V | 84.0V | 87.6V | 4A | 0.8 | 0.2 | ||
| Note: Cut-off point for Li battery is 5% of CC, and it can be setted between 3-10%. | |||||||||
Gemera Spec:
| Compatible Battery | Lead Acid/LiFePo4/Li-ion/Li-MnO2 | ||
| Input | 90 to 240 VAC 50/60Hz | ||
| Output | 67.2V 5A | ||
| Charge voltage (Lead Acid) |
73.5V (Lead acid battery voltage is 60V) |
Float Voltage (Lead acid) |
57.0V |
| LiFePo4/3.65V Charge voltage (S:connect in series) |
65.7V18S LiFePO4 battery voltage is 3.65V CC mode |
||
| Lithium ion/4.2V Charge voltage (S:connect in series) |
67.2V 16S Li-ion battery voltage is 4.2V <0.6A |
||
| LED Indicator | Solid Red LED = Charging (0-99%) Solid Green LED = Fully charged (100%) |
||
| Dimension(LxWxH) | L180xW90xH65 mm | ||
| Weight | 1.2Kg | ||
| Charging Mode | CC/CV, Float/cut-off | ||
| Certification | UL/cUL / ETL / CE / FCC / RoHS, EN61558 / ETL1310 Approval Standard. Recognized or tested by TUV lab, for more information, please contact us. | ||
| Charging Time | Cut-off point for Li battery is 8% of CC and it can be set between 3-10%.(charging time:4-5 hours) | ||
| Transition for Lead acid charger is 25% of CC.(charging time:6-8 hours) | |||
| Protection | Over Current, Over Voltage, Over temperature, Short Circuit, Reverse Polarity, shut off or trickle and anti-reverse charge. | ||
| Advantage | 1). Intelligent cooling fun, controlled by temperatureQuasi-resonant pulse width modulation(PWM),full automatic transition of CC,CV and Float/Cut-off, meet the demands for different Curve. 2). Aluminum case, Robust, Elegant and Reliable. |
||
Protections :
1.Over Current Protection
2. Over Voltage Protection
3. Short circuit protection
4. Reverse input protection
Remark (please kindly focus on it)
1.Rechangeable input plug(Customized) , So please confirm it
2.Output Connector: DC, JST, XRL, Alligator Clip,Air plug and so on, So please confirm it
3.For the Necessary quality Certifications, please confirm before ordering
4.For delivery time , We should confirm with each other ,as we do global big business
5.Trust our quality and Recommendation, As we are Global famous Brand EMC
Our Service:
1.24-Hours Online. Your offer will be respond promptly.
2.OEM, ODM, Wholesale are welcomed.
3.Please feel free to contact us.
Our Company other hot selling products
FAQ
(1). How do we place an order?
Please kindly send us an email specifying the item, quantity, payment
or other specification to place an order.
(2). Your battery can meet CE RoHS requirements?
Our battery are with the certificate of CE/RoHS.
(3). How would the goods be shipped?
We ship via UPS,DHL ,FEDEX and sea transportation normally.
(4). Can you print my picture or logo on the battery cover?
Yes, OEM is available,we can print your picture or logo on the battery case, and you can offer your logo.
(5). What kind of guarantee you give?
Our battery the warranty time is 1year .
